Final Restoration 10 Days After ALX-BT Implant Placement

Case Summary 🔎

Patient Information

• Age / Sex: 53-year-old female

• Medical History: Healthy

• Diagnosis: #46 healed edntulos site

• Treatment plan:

  1) #46 ALX-BT implant placement

  2) Early loading of single crown implant




  1️⃣Pre-op

• Preoperative panoramic radiograph showing the healed edentulous site at #46.

2️⃣Surgery

• #46 healed edentulous site, with mild concavity & limited keratinized tissue of buccal gingival tissue.

• CMI Bone densities & Drilling bursteps:

  - #46 (D233): D2.2-D3.0-D3.5 with L11.5mm & Final drilling burs with D4.2/ L10mm, D4.mm/ L3m.









• 30/6/2026: #46 ALX-BT implant placement with D(neck)4.5/ D(body)5.0/ L10mm

• Packing moldable Xenograft for performing buccal contour augmentation.









• 30/6/2026: After #46 suturing, IST remeasurement #46 IST value =80(+2).

• Connecting #46 ALX-BT implant with scan body, digital impression for fabricating full Zirconia crown implant.









• #46 Full Zirconia crown implant









• 10/7/2026: After #46 implant placement 10days, IST remeasurement #46 IST value = 85(+2).

• 10/7/2026: #46 Final crown implant delivery.

3️⃣Before & After Summary
